Product Brief
Designed specifically for underground coal mine workers, this intelligent storage device integrates identity recognition, IoT sensing, environmental monitoring, and remote management. It enables digital, intelligent management of miners' clothing changes, uniform replacement, and protective equipment storage, plus automatic heating, ventilation, deodorization, and disinfection functions, and suits locker rooms, dispatch rooms, and bathing areas.
Door Quantity:6P
Op. Temp:- 20℃~+50℃
Power: ≤100W
Critical Core Technologies
Huining Technology has focused on the R&D and manufacturing of industrial intelligent charging cabinets for 18 years, and has always been committed to providing efficient, safe and intelligent management solutions for enterprises in the industrial field.
Relying on continuous technological innovation and profound industry accumulation, Huining Technology has mastered a number of key core technologies for intelligent charging cabinets and built a complete independent intellectual property system. At present, it has obtained 11 national patents and 7 software copyrights, The technological achievements cover core modules such as hardware structure design, intelligent identification and control, charging safety management, big data analysis, and platform integration.
Relying on continuous technological innovation and profound industry accumulation, Huining Technology has mastered a number of key core technologies for intelligent charging cabinets and built a complete independent intellectual property system. At present, it has obtained 11 national patents and 7 software copyrights, The technological achievements cover core modules such as hardware structure design, intelligent identification and control, charging safety management, big data analysis, and platform integration.
Patent Numbers：CN222091134U、CN222107619U、CN221961607U、CN221613345U、CN221281561U、CN219267061U、CN219267009U、CN219228201U、CN219228016U、CN219228015U, etc.
Software Copyrights：Attendance Management System for Mine Lamp Charging Cabinets、Main Control System Management Software for Intelligent Charging Cabinets、Operation Control Software for Intelligent Charging Cabinets、Personnel Information Management System for Biometric Identification Intelligent Mine Lamp Cabinets、Data Statistics Platform for Mine Lamp Charging Cabinets、Alarm Management System for Intelligent Charging Cabinets、Monitoring and Management System for Intelligent Charging Cabinets.
Independent R&D ,Original Design
It supports multiple recognition methods—facial, iris, and card swiping—with free switching. It enables second-fast cabinet opening, accurately identifies miners' identities and miner lamp information, and realizes a full-process closed loop of "one person, one lamp, one cabinet".
Iris Recognition
Face Recognition
Card Recognition
Remote Control
Intelligent Access and Convenient Traceability
It automatically records time, personnel and cabinet-opening actions per use, triggers alarms for abnormal opening or prolonged non-return, and supports remote cabinet opening and fault handling.
Intelligent Sensing and Environmental Control
It has built-in temperature/humidity sensors and smoke/gas detectors, monitors the cabinet’s internal environment in real time, automatically adjusts environmental indicators, and ensures constant comfort and safety inside.
Remote Monitoring & Intelligent O&M
Cloud-Based Remote Management enables real-time access to device status, one-click push of abnormal alarms, and more efficient operation and maintenance.
Performance Parameters
Two-Door Iris Intelligent Locker
Four-Door Iris Intelligent Locker
Four-Door Intelligent Locker
Six-Door Intelligent Locker
| Product Name | Two-Door Iris Intelligent Locker | Overall Dimensions | 750×500×2100mm | Efficiency | ≥85% |
| Equipment Model | HN-GYG-2 | Input Frequency | 50Hz±15% | Total Machine Power | ≤100W |
| Cabinet Material | Stainless Steel with Surface Powder Coating | Overall Weight | 40kg | Operating Temperature | -5℃~40℃ |
| Number of Cabinet Doors | 2 Doors | Input Current | AC<6.0A | Operating Humidity | ≤95%RH |
| Display Screen | 2.8" / 3.5" Color Display | Input Voltage Range | Single-Phase AC 220V ±10% | Storage Temperature | -20℃~60℃ |
| Door Lock | Magnetic Lock Fingerprint Keypad Lock | Rated Duty System | Continuous Duty System | Storage Humidity | ≤90%RH |
| Product Name | Four-Door Iris Intelligent Locker | Overall Dimensions | 950×500×1940mm | Efficiency | ≥85% |
| Equipment Model | HN-GYG-4 | Input Frequency | 50Hz±15% | Total Machine Power | ≤100W |
| Cabinet Material | Stainless Steel with Surface Powder Coating | Overall Weight | 80kg | Operating Temperature | -5℃~40℃ |
| Number of Cabinet Doors | 4 Doors | Input Current | AC<6.0A | Operating Humidity | ≤95%RH |
| Display Screen | 2.8" / 3.5" Color Display | Input Voltage Range | Single-Phase AC 220V ±10% | Storage Temperature | -20℃~60℃ |
| Door Lock | Magnetic Lock Fingerprint Keypad Lock | Rated Duty System | Continuous Duty System | Storage Humidity | ≤90%RH |
| Product Name | Four-Door Intelligent Locker | Overall Dimensions | 950×500×1940mm | Efficiency | ≥85% |
| Equipment Model | HN-GYG-4 | Input Frequency | 50Hz±15% | Total Machine Power | ≤100W |
| Cabinet Material | Stainless Steel with Surface Powder Coating | Overall Weight | 80kg | Operating Temperature | -5℃~40℃ |
| Number of Cabinet Doors | 4 Doors | Input Current | AC<6.0A | Operating Humidity | ≤95%RH |
| Display Screen | 2.8" / 3.5" Color Display | Input Voltage Range | Single-Phase AC 220V ±10% | Storage Temperature | -20℃~60℃ |
| Door Lock | Magnetic Lock Fingerprint Keypad Lock | Rated Duty System | Continuous Duty System | Storage Humidity | ≤90%RH |
| Product Name | Six-Door Intelligent Locker | Overall Dimensions | 1480×460×2080mm | Efficiency | ≥85% |
| Equipment Model | HN-GYG-6 | Input Frequency | 50Hz±15% | Total Machine Power | ≤100W |
| Cabinet Material | Stainless Steel with Surface Powder Coating | Overall Weight | 100kg | Operating Temperature | -5℃~40℃ |
| Number of Cabinet Doors | 6 Doors | Input Current | AC<6.0A | Operating Humidity | ≤95%RH |
| Display Screen | 2.8" / 3.5" Color Display | Input Voltage Range | Single-Phase AC 220V ±10% | Storage Temperature | -20℃~60℃ |
| Door Lock | Magnetic Lock Fingerprint Keypad Lock | Rated Duty System | Continuous Duty System | Storage Humidity | ≤90%RH |
Actual Shot Display
Successful Cases
Jude Coal Industry
Product Name：
Multimodal Intelligent Cap Lamp Charging Cabinet
Purchase Quantity：
35 Units
Product Configuration：
Iris Recognition, 100 Cabinet Positions
27-Inch Display Screen, 5.5-Inch Color Screen, LED Scrolling Large Screen, Cold-Rolled Steel (with Surface Powder Coating)...
Customer Reviews：
The product features stable and reliable performance, outstanding quality, simple operation, powerful functions, and excellent value for money!
Yanghe Coal Industry
Product Name：
Blue-Screen Intelligent Cap Lamp Charging Cabinet
Purchase Quantity：
22 Units
Product Configuration：
Iris Recognition, 100 Cabinet Positions, 2.2-Inch Blue Screen, LED Scrolling Large Screen, Cold-Rolled Steel (with Surface Powder Coating)...
Customer Reviews：
The product features stable and reliable performance, outstanding quality, simple operation, powerful functions, and excellent value for money!
Mengjiayao Coal Industry
Product Name：
Stainless Steel Intelligent
Cap Lamp Charging Cabinet
Purchase Quantity：
14 Units
Product Configuration：
Iris Recognition, 100 Cabinet Positions, 5.5-Inch Color Screen, LED Scrolling Large Screen, 201 Stainless Steel...
Customer Reviews：
The product features stable and reliable performance, outstanding quality, simple operation, powerful functions, and excellent value for money!
Qinxiu Coal Industry
Product Name：
Color-Screen Intelligent
Cap Lamp Charging Cabine
Purchase Quantity：
10 Units
Product Configuration：
Iris Recognition, 100 Cabinet Positions, 5.5-Inch Color Screen, LED Scrolling Large Screen, Cold-Rolled Steel (with Surface Powder Coating)...
Customer Reviews：
The product features stable and reliable performance, outstanding quality, simple operation, powerful functions, and excellent value for money!
